Soundproof Fiberglass Insulation Perforated Wood Acoustic Panels Wooden Board

Guangdong Bunge Building Material Industrial Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment

Soundproof Fiberglass Insulation Perforated Wood Acoustic Panels Wooden Board

  • 1
  • 2
  • 3

Brand Name : BUNGE

Model Number : Perforated acoustic wall panels

Certification : ISO9001

Place of Origin : Guangdong

MOQ : 100 square meters

Price : US Dollars 9.5 - 32.9 per square meters

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal

Supply Ability : 200000 square meters per month

Delivery Time : 7 - 15 days

Packaging Details : Cartons or according to customer's request

Fire resistance : China Standard Class B1

Thickness : 12 / 15 / 18 mm

Position : Interior

Material : MDF Board

Service : OEM,ODM

Application : Church,conference room,KTV

Product name : Perforated acoustic wall panels

Surface : Melamine,Veneer

Color : Accept customized

Contact Now

Features:
1 Perforated wood acoustic soundproof wall panel is a kind of resonance absorption material with holes through on the quality MDF board.



2 It has strong selection on the sound spectrum and particular great performance on the middle and low requency.


3 If filled with the acoustic cotton at the back side space of the acoustic panel, it has better performance on the middle and high frequency.


4 The holes diameter and pitch can be custom made.


5 Strong impact resistance, excellent decorate performance, elegant color, especially work for wooden construction.


Soundproof Fiberglass Insulation Perforated Wood Acoustic Panels Wooden Board

Product Description:
Perforated acoustic panel : BANGE perforated acoustic panel used high density mold- proof, fireproof, enviromental eco-pine wood as base material, processed by full automatic computer controled equipment. Be made to multihole structures product, not only have good sound absorbing effect, but also looks great on visual.


Model type E16/6,E32/6,V32/6,E35/1.5-10,V32/3-10
Size6 600*600,1200*600,2400*1200mm
Thickness 12,15,18mm
Finish melamine, veneer, metal finish, acrylic, PU leather,
paint UV,PU painting
Base material Standard MDF, Eco-pine wood MDF, Fireproof MDF, Moistureproof MDF, Magnesium Composited MDF
MDF density 680kg/cubic meter
Backside finish acoustic felt, woven fabric
Fireproof grade GB8624 2012 A,B1,B2,B3
Eco-protection grade E0,E1
Installation aluminum keel and clips, wood frame, gun nail
Backside hole diameter 10 mm
Depth of groove 7mm
Veneer type thickness 0.3,0.6mm
Veneer texture Mountain texture, straight line
Veneer tree species Maple, cherry, Oak, teak, walnut, ashtree, sabelli, birch,
Certification BV,CE,SGS,ISO9001-2008,
Test report Eco protection, sound absorption, flame retardant


Soundproof Fiberglass Insulation Perforated Wood Acoustic Panels Wooden Board

Installtion Method:

1> First fix the aluminum profile onto the wooden frame or bottom board, and their distance suggested 6about 600mm.

2> Filled the 32-64kg/m density acoustic foam among aluminum profiles.

3> Use the clips to fix the perforated acoustic panel to the aluminum profile.

4> When install several acoustic panel, the distance between noses to noses suggested 2-3mm.

5> If install the acoustic panel in the horizontal way, then the notch of the panel should face down, and it need to be fixed tight with clips. After that install pieces and pieces of acoustic panel onto the lowest one.

Soundproof Fiberglass Insulation Perforated Wood Acoustic Panels Wooden Board

Perforated wall panels performances:

Acoustic absorption is usually defined in terms of an absorption coefficient(usually denoted by the Greek letter alpha, α), defined as the ratio of absorbed to incident sound energy from a single interaction between a sound wave and a certain material. Absorption coefficients range from 0 to 1 and vary with frequency, α=0 means that the material absorbs no sound and reflects all sound energy incident on it.
α=1 means that the material absorbs all sound energy incident on it and reflects none. Absorption coefficients of 0 and 1 are ideal values that do not exist in reality because all materials reflect and absorb some sound. In general, materials having absorption coefficients less than 0.15 are considered to be reflective and those having absorption coefficients greater than 0.4 are considered to be absorptive.

As you can see our Testing report show that our products have a very good performance in a
large range of application.
